SAE 37° JIC Flare Fittings
SAE JIC 37° Sleeves
Hydraulic, instrumentation, and chemical processing systems. Pressure rated up to 10,000 P.S.I. depending on tube and fitting size. Good vibration resistance, decreasing with tube size. Temperature range of -65°F to +400°F. Made from Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Used with various tubing types. Choice of 2 or 3 piece design. Meets ASA, ASME, SAE, and MS specifications.
| Tube OD | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|
| 1/4" | Carbon Steel | Sleeve | 5,000 P.S.I. | 15 |
C5165X4
|
Log in to view price |
|
|
||||||
| 3/8" | Carbon Steel | Sleeve | 5,000 P.S.I. | 15 |
C5165X6
|
Log in to view price |
|
|
||||||
| 1/2" | Carbon Steel | Sleeve | 4,500 P.S.I. | 15 |
C5165X8
|
Log in to view price |
|
|
||||||
| 3/4" | Carbon Steel | Sleeve | 3,500 P.S.I. | 15 |
C5165X12
|
Log in to view price |
|
Item Number: C5165X12
Package Weight: 0.4 lbs
|
||||||
| 1" | Carbon Steel | Sleeve | 3,500 P.S.I. | 15 |
C5165X16
|
Log in to view price |
|
|
||||||
SAE JIC 37° Nuts
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 5/16"-24 | Carbon Steel | Nut | 5,000 P.S.I. | 10 |
C5105X2
|
Log in to view price |
|
|
|||||||
| 3/16" | 3/8"-24 | Carbon Steel | Nut | 5,000 P.S.I. | 10 |
C5105X3
|
Log in to view price |
|
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | Nut | 5,000 P.S.I. | 10 |
C5105X4
|
Log in to view price |
|
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Nut | 5,000 P.S.I. | 10 |
C5105X5
|
Log in to view price |
|
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Nut | 5,000 P.S.I. | 10 |
C5105X6
|
Log in to view price |
|
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Nut | 4,500 P.S.I. | 10 |
C5105X8
|
Log in to view price |
|
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Nut | 3,500 P.S.I. | 10 |
C5105X10
|
Log in to view price |
|
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Nut | 3,500 P.S.I. | 10 |
C5105X12
|
Log in to view price |
|
|
|||||||
| 7/8" | 1-3/16"-12 | Carbon Steel | Nut | 3,000 P.S.I. | 5 |
C5105X14
|
Log in to view price |
|
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Nut | 3,000 P.S.I. | 5 |
C5105X16
|
Log in to view price |
|
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Nut | 2,500 P.S.I. | 2 |
C5105X20
|
Log in to view price |
|
|
|||||||
SAE JIC 37° Bulkhead Nuts
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made from Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Bulkhead Nut | 5,000 P.S.I. | 10 |
C5924X4
|
Log in to view price |
|
Item Number: C5924X4
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Bulkhead Nut | 5,000 P.S.I. | 10 |
C5924X6
|
Log in to view price |
|
Item Number: C5924X6
Package Weight: 0.4 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Bulkhead Nut | 4,500 P.S.I. | 10 |
C5924X8
|
Log in to view price |
|
Item Number: C5924X8
Package Weight: 0.4 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Bulkhead Nut | 3,500 P.S.I. | 10 |
C5924X10
|
Log in to view price |
|
Item Number: C5924X10
Package Weight: 0.5 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Bulkhead Nut | 3,500 P.S.I. | 5 |
C5924X12
|
Log in to view price |
|
Item Number: C5924X12
Package Weight: 0.5 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Bulkhead Nut | 3,000 P.S.I. | 5 |
C5924X16
|
Log in to view price |
|
Item Number: C5924X16
Package Weight: 0.6 lbs
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Bulkhead Nut | 2,500 P.S.I. | 2 |
C5924X20
|
Log in to view price |
|
Item Number: C5924X20
Package Weight: 0.2 lbs
|
|||||||
SAE JIC 37° Caps
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 5/16"-24 | Carbon Steel | Cap | 5,000 P.S.I. | 5 |
C5129X2
|
Log in to view price |
|
|
|||||||
| 3/16" | 3/8"-24 | Carbon Steel | Cap | 5,000 P.S.I. | 5 |
C5129X3
|
Log in to view price |
|
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | Cap | 5,000 P.S.I. | 5 |
C5129X4
|
Log in to view price |
|
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Cap | 5,000 P.S.I. | 5 |
C5129X5
|
Log in to view price |
|
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Cap | 5,000 P.S.I. | 5 |
C5129X6
|
Log in to view price |
|
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Cap | 4,500 P.S.I. | 5 |
C5129X8
|
Log in to view price |
|
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Cap | 3,500 P.S.I. | 5 |
C5129X10
|
Log in to view price |
|
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Cap | 3,500 P.S.I. | 5 |
C5129X12
|
Log in to view price |
|
|
|||||||
| 7/8" | 1-3/16"-12 | Carbon Steel | Cap | 3,000 P.S.I. | 1 |
C5129X14
|
Log in to view price |
|
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Cap | 3,000 P.S.I. | 2 |
C5129X16
|
Log in to view price |
|
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Cap | 2,500 P.S.I. | 1 |
C5129X20
|
Log in to view price |
|
|
|||||||
| 1-1/2" | 1-7/8"-12 | Carbon Steel | Cap | 2,000 P.S.I. | 1 |
C5129X24
|
Log in to view price |
|
|
|||||||
SAE JIC 37° Plugs
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/16" | 3/8"-24 | Carbon Steel | Plug | 5,000 P.S.I. | 2 |
C5229X3
|
Log in to view price |
|
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | Plug | 5,000 P.S.I. | 5 |
C5229X4
|
Log in to view price |
|
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Plug | 5,000 P.S.I. | 5 |
C5229X5
|
Log in to view price |
|
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Plug | 5,000 P.S.I. | 5 |
C5229X6
|
Log in to view price |
|
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Plug | 4,500 P.S.I. | 5 |
C5229X8
|
Log in to view price |
|
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Plug | 3,500 P.S.I. | 5 |
C5229X10
|
Log in to view price |
|
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Plug | 3,500 P.S.I. | 2 |
C5229X12
|
Log in to view price |
|
|
|||||||
| 7/8" | 1-3/16"-12 | Carbon Steel | Plug | 3,000 P.S.I. | 2 |
C5229X14
|
Log in to view price |
|
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Plug | 3,000 P.S.I. | 2 |
C5229X16
|
Log in to view price |
|
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Plug | 2,500 P.S.I. | 2 |
C5229X20
|
Log in to view price |
|
|
|||||||
| 1-1/2" | 1-7/8"-12 | Carbon Steel | Plug | 2,000 P.S.I. | 1 |
C5229X24
|
Log in to view price |
|
|
|||||||
| 2" | 2-1/2"-12 | Carbon Steel | Plug | 1,500 P.S.I. | 1 |
C5229X32
|
Log in to view price |
|
|
|||||||
SAE JIC 37° 2-Piece Reducers
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made from Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/8" x 1/4" | 9/16"-18 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5015X6X4
|
Log in to view price |
|
Item Number: C5015X6X4
Package Weight: 0.1 lbs
|
|||||||
| 1/2" x 1/4" | 3/4"-16 | Carbon Steel | Reducer | 4,500 P.S.I. | 2 |
C5015X8X4
|
Log in to view price |
|
Item Number: C5015X8X4
Package Weight: 0.1 lbs
|
|||||||
| 1/2" x 3/8" | 3/4"-16 | Carbon Steel | Reducer | 4,500 P.S.I. | 2 |
C5015X8X6
|
Log in to view price |
|
Item Number: C5015X8X6
Package Weight: 0.1 lbs
|
|||||||
| 3/4" x 1/4" | 1-1/16"-12 | Carbon Steel | Reducer | 3,500 P.S.I. | 2 |
C5015X12X4
|
Log in to view price |
|
Item Number: C5015X12X4
Package Weight: 0.1 lbs
|
|||||||
| 3/4" x 3/8" | 1-1/16"-12 | Carbon Steel | Reducer | 3,500 P.S.I. | 2 |
C5015X12X6
|
Log in to view price |
|
Item Number: C5015X12X6
Package Weight: 0.1 lbs
|
|||||||
| 3/4" x 1/2" | 1-1/16"-12 | Carbon Steel | Reducer | 3,500 P.S.I. | 2 |
C5015X12X8
|
Log in to view price |
|
Item Number: C5015X12X8
Package Weight: 0.2 lbs
|
|||||||
| 1" x 5/8" | 1-5/16"-12 | Carbon Steel | Reducer | 3,000 P.S.I. | 1 |
C5015X1610
|
Log in to view price |
|
Item Number: C5015X1610
Package Weight: 0.2 lbs
|
|||||||
| 1" x 3/4" | 1-5/16"-12 | Carbon Steel | Reducer | 3,000 P.S.I. | 2 |
C5015X1612
|
Log in to view price |
|
Item Number: C5015X1612
Package Weight: 0.4 lbs
|
|||||||
| 1-1/4" x 3/4" | 1-5/8"-12 | Carbon Steel | Reducer | 2,500 P.S.I. | 1 |
C5015X2012
|
Log in to view price |
|
Item Number: C5015X2012
Package Weight: 0.3 lbs
|
|||||||
| 1-1/4" x 1" | 1-5/8"-12 | Carbon Steel | Reducer | 2,500 P.S.I. | 1 |
C5015X2016
|
Log in to view price |
|
Item Number: C5015X2016
Package Weight: 0.3 lbs
|
|||||||
SAE JIC 37° Reducers
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/8" x 1/4" | 9/16"-18 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X6X4
|
Log in to view price |
|
Item Number: C5016X6X4
Package Weight: 0.1 lbs
|
|||||||
| 1/2" x 1/4" | 3/4"-16 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X8X4
|
Log in to view price |
|
Item Number: C5016X8X4
Package Weight: 0.2 lbs
|
|||||||
| 1/2" x 3/8" | 3/4"-16 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X8X6
|
Log in to view price |
|
Item Number: C5016X8X6
Package Weight: 0.2 lbs
|
|||||||
| 5/8" x 1/4" | 7/8"-14 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X10X4
|
Log in to view price |
|
Item Number: C5016X10X4
Package Weight: 0.3 lbs
|
|||||||
| 5/8" x 3/8" | 7/8"-14 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X10X6
|
Log in to view price |
|
Item Number: C5016X10X6
Package Weight: 0.3 lbs
|
|||||||
| 5/8" x 1/2" | 7/8"-14 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X10X8
|
Log in to view price |
|
Item Number: C5016X10X8
Package Weight: 0.3 lbs
|
|||||||
| 3/4" x 1/4" | 1-1/16"-12 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X12X4
|
Log in to view price |
|
Item Number: C5016X12X4
Package Weight: 0.5 lbs
|
|||||||
| 3/4" x 3/8" | 1-1/16"-12 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X12X6
|
Log in to view price |
|
Item Number: C5016X12X6
Package Weight: 0.4 lbs
|
|||||||
| 3/4" x 1/2" | 1-1/16"-12 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X12X8
|
Log in to view price |
|
Item Number: C5016X12X8
Package Weight: 0.5 lbs
|
|||||||
| 3/4" x 5/8" | 1-1/16"-12 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X1210
|
Log in to view price |
|
Item Number: C5016X1210
Package Weight: 0.5 lbs
|
|||||||
| 1" x 5/8" | 1-5/16"-12 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X1610
|
Log in to view price |
|
Item Number: C5016X1610
Package Weight: 0.7 lbs
|
|||||||
| 1" x 3/4" | 1-5/16"-12 | Carbon Steel | Reducer | 5,000 P.S.I. | 2 |
C5016X1612
|
Log in to view price |
|
Item Number: C5016X1612
Package Weight: 0.7 lbs
|
|||||||
SAE JIC 37° Swivel Unions
TYPICAL APPLICATION includes hydraulic, instrumentation, and chemical processing systems. PRESSURE ratings reach up to 10,000 P.S.I. depending on tube and fitting size. VIBRATION RATING offers good resistance, decreasing with larger tube sizes. TEMPERATURE RANGE spans from -65°F to +400°F. Constructed from Carbon Steel - AISI/SAE 12L14 with a Zinc finish.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Union | 5,000 P.S.I. | 2 |
9101X4X4
|
Log in to view price |
|
Item Number: 9101X4X4
Package Weight: 0.1 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Union | 5,000 P.S.I. | 2 |
9101X6X6
|
Log in to view price |
|
Item Number: 9101X6X6
Package Weight: 0.2 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Union | 4,500 P.S.I. | 2 |
9101X8X8
|
Log in to view price |
|
Item Number: 9101X8X8
Package Weight: 0.3 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Union | 3,500 P.S.I. | 1 |
9101X10X10
|
Log in to view price |
|
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Union | 3,500 P.S.I. | 1 |
9101X12X12
|
Log in to view price |
|
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Union | 3,000 P.S.I. | 1 |
9101X16X16
|
Log in to view price |
|
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Union | 2,500 P.S.I. | 1 |
9101X20X20
|
Log in to view price |
|
|
|||||||
| 1-1/2" | 1-7/8"-12 | Carbon Steel | Union | 2,000 P.S.I. | 1 |
9101X24X24
|
Log in to view price |
|
Item Number: 9101X24X24
Package Weight: 1.4 lbs
|
|||||||
SAE JIC 37° Small Hex Unions
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/16" | 3/8"-24 | Carbon Steel | Union | 5,000 P.S.I. | 5 |
C5305X3
|
Log in to view price |
|
Item Number: C5305X3
Package Weight: 0.1 lbs
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | Union | 5,000 P.S.I. | 5 |
C5305X4
|
Log in to view price |
|
Item Number: C5305X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Union | 5,000 P.S.I. | 5 |
C5305X5
|
Log in to view price |
|
Item Number: C5305X5
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Union | 5,000 P.S.I. | 5 |
C5305X6
|
Log in to view price |
|
Item Number: C5305X6
Package Weight: 0.3 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Union | 4,500 P.S.I. | 5 |
C5305X8
|
Log in to view price |
|
Item Number: C5305X8
Package Weight: 0.6 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Union | 3,500 P.S.I. | 2 |
C5305X10
|
Log in to view price |
|
Item Number: C5305X10
Package Weight: 0.4 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Union | 3,500 P.S.I. | 2 |
C5305X12
|
Log in to view price |
|
Item Number: C5305X12
Package Weight: 0.6 lbs
|
|||||||
| 7/8" | 1-3/16"-12 | Carbon Steel | Union | 3,000 P.S.I. | 2 |
C5305X14
|
Log in to view price |
|
Item Number: C5305X14
Package Weight: 0.8 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Union | 3,000 P.S.I. | 2 |
C5305X16
|
Log in to view price |
|
Item Number: C5305X16
Package Weight: 0.9 lbs
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Union | 2,500 P.S.I. | 1 |
C5305X20
|
Log in to view price |
|
Item Number: C5305X20
Package Weight: 0.7 lbs
|
|||||||
| 1-1/2" | 1-7/8"-12 | Carbon Steel | Union | 2,000 P.S.I. | 1 |
C5305X24
|
Log in to view price |
|
Item Number: C5305X24
Package Weight: 1 lbs
|
|||||||
| 2" | 2-1/2"-12 | Carbon Steel | Union | 1,500 P.S.I. | 1 |
C5305X32
|
Log in to view price |
|
Item Number: C5305X32
Package Weight: 2.2 lbs
|
|||||||
SAE JIC 37° Large Hex Unions
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Union | 5,000 P.S.I. | 5 |
C5306X4
|
Log in to view price |
|
Item Number: C5306X4
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Union | 5,000 P.S.I. | 2 |
C5306X6
|
Log in to view price |
|
Item Number: C5306X6
Package Weight: 0.2 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Union | 4,500 P.S.I. | 2 |
C5306X8
|
Log in to view price |
|
Item Number: C5306X8
Package Weight: 0.3 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Union | 3,500 P.S.I. | 2 |
C5306X10
|
Log in to view price |
|
Item Number: C5306X10
Package Weight: 0.4 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Union | 3,500 P.S.I. | 2 |
C5306X12
|
Log in to view price |
|
Item Number: C5306X12
Package Weight: 0.8 lbs
|
|||||||
SAE JIC 37° Bulkhead Unions
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made from Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/16" | 3/8"-24 | Carbon Steel | Bulkhead Union | 5,000 P.S.I. | 2 |
C5325X3
|
Log in to view price |
|
Item Number: C5325X3
Package Weight: 0.5 lbs
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | Bulkhead Union | 5,000 P.S.I. | 2 |
C5325X4
|
Log in to view price |
|
Item Number: C5325X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Bulkhead Union | 5,000 P.S.I. | 2 |
C5325X5
|
Log in to view price |
|
Item Number: C5325X5
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Bulkhead Union | 5,000 P.S.I. | 2 |
C5325X6
|
Log in to view price |
|
Item Number: C5325X6
Package Weight: 0.2 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Bulkhead Union | 4,500 P.S.I. | 2 |
C5325X8
|
Log in to view price |
|
Item Number: C5325X8
Package Weight: 0.5 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Bulkhead Union | 3,500 P.S.I. | 2 |
C5325X10
|
Log in to view price |
|
Item Number: C5325X10
Package Weight: 0.6 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Bulkhead Union | 3,500 P.S.I. | 2 |
C5325X12
|
Log in to view price |
|
Item Number: C5325X12
Package Weight: 1 lbs
|
|||||||
| 7/8" | 1-3/16"-12 | Carbon Steel | Bulkhead Union | 3,000 P.S.I. | 1 |
C5325X14
|
Log in to view price |
|
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Bulkhead Union | 3,000 P.S.I. | 1 |
C5325X16
|
Log in to view price |
|
|
|||||||
SAE JIC 37° Bulkhead Union Assemblies
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +4,000°F. Made of Carbon Steel - AISI/SAE 12L14 and zinc plated. Available in two- or three-piece designs, meeting ASA, ASME, SAE, and MS specifications.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Bulkhead Union | 5,000 P.S.I. | 1 |
C5700X4
|
Log in to view price |
|
Item Number: C5700X4
Package Weight: 0.1 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Bulkhead Union | 5,000 P.S.I. | 1 |
C5700X6
|
Log in to view price |
|
Item Number: C5700X6
Package Weight: 0.1 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Bulkhead Union | 4,500 P.S.I. | 1 |
C5700X8
|
Log in to view price |
|
Item Number: C5700X8
Package Weight: 0.3 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Bulkhead Union | 3,500 P.S.I. | 1 |
C5700X10
|
Log in to view price |
|
Item Number: C5700X10
Package Weight: 0.4 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Bulkhead Union | 3,500 P.S.I. | 1 |
C5700X12
|
Log in to view price |
|
Item Number: C5700X12
Package Weight: 0.6 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Bulkhead Union | 3,000 P.S.I. | 1 |
C5700X16
|
Log in to view price |
|
Item Number: C5700X16
Package Weight: 0.8 lbs
|
|||||||
SAE JIC 37° to Female Pipe Thread 45° Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Good vibration resistance, decreasing with larger tube sizes. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc finish.
| Tube OD | Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5357X4X4
|
Log in to view price |
|
Item Number: C5357X4X4
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5357X6X6
|
Log in to view price |
|
Item Number: C5357X6X6
Package Weight: 0.3 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | 45° Elbow | 4,500 P.S.I. | 2 |
C5357X8X8
|
Log in to view price |
|
Item Number: C5357X8X8
Package Weight: 0.7 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | 45° Elbow | 3,500 P.S.I. | 1 |
C5357X1212
|
Log in to view price |
|
Item Number: C5357X1212
Package Weight: 0.6 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | 45° Elbow | 3,000 P.S.I. | 1 |
C5357X1616
|
Log in to view price |
|
Item Number: C5357X1616
Package Weight: 0.9 lbs
|
||||||||
SAE JIC 37° Male Connectors
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
Tube OD: 1/8"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 5/16"-24 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X2
|
Log in to view price |
|
Item Number: C5205X2
Package Weight: 0.2 lbs
|
|||||||
Tube OD: 3/16"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 3/8"-24 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X3
|
Log in to view price |
|
Item Number: C5205X3
Package Weight: 0.2 lbs
|
|||||||
Tube OD: 1/4"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X4
|
Log in to view price |
|
Item Number: C5205X4
Package Weight: 0.2 lbs
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X4X4
|
Log in to view price |
|
Item Number: C5205X4X4
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X4X6
|
Log in to view price |
|
Item Number: C5205X4X6
Package Weight: 0.5 lbs
|
|||||||
| 1/2" | 7/16"-20 | Carbon Steel | Straight | 4,500 P.S.I. | 5 |
C5205X4X8
|
Log in to view price |
|
Item Number: C5205X4X8
Package Weight: 0.7 lbs
|
|||||||
Tube OD: 5/16"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X5
|
Log in to view price |
|
Item Number: C5205X5
Package Weight: 0.2 lbs
|
|||||||
| 1/4" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X5X4
|
Log in to view price |
|
Item Number: C5205X5X4
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X5X6
|
Log in to view price |
|
Item Number: C5205X5X6
Package Weight: 0.5 lbs
|
|||||||
Tube OD: 3/8"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X6X2
|
Log in to view price |
|
Item Number: C5205X6X2
Package Weight: 0.3 lbs
|
|||||||
| 1/4" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X6
|
Log in to view price |
|
Item Number: C5205X6
Package Weight: 0.4 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5205X6X6
|
Log in to view price |
|
Item Number: C5205X6X6
Package Weight: 0.5 lbs
|
|||||||
SAE JIC 37° Female Swivel Unions
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from 65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Interchangeable with copper, brass, steel, and aluminum tubing.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Straight | 10,000 P.S.I. | 1 |
9705X4
|
Log in to view price |
|
Item Number: 9705X4
Package Weight: 0 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Straight | 10,000 P.S.I. | 1 |
9705X6
|
Log in to view price |
|
Item Number: 9705X6
Package Weight: 0.1 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Straight | 10,000 P.S.I. | 1 |
9705X8
|
Log in to view price |
|
Item Number: 9705X8
Package Weight: 0.1 lbs
|
|||||||
| 3/4" | 11/16"-12 | Carbon Steel | Straight | 10,000 P.S.I. | 1 |
9705X12
|
Log in to view price |
|
Item Number: 9705X12
Package Weight: 0.4 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Straight | 10,000 P.S.I. | 1 |
9705X16
|
Log in to view price |
|
Item Number: 9705X16
Package Weight: 0.6 lbs
|
|||||||
SAE JIC 37° to Male Straight Thread Adapters
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 2 |
C5216X4X4
|
Log in to view price |
|
Item Number: C5216X4X4
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 2 |
C5216X6X6
|
Log in to view price |
|
Item Number: C5216X6X6
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 1/2" | 9/16"-18 | Carbon Steel | Straight | 4,500 P.S.I. | 2 |
C5216X6X8
|
Log in to view price |
|
Item Number: C5216X6X8
Package Weight: 0.3 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | Straight | 4,500 P.S.I. | 2 |
C5216X8X8
|
Log in to view price |
|
Item Number: C5216X8X8
Package Weight: 0.3 lbs
|
||||||||
| 5/8" | 5/8" | 7/8"-14 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
C5216X1010
|
Log in to view price |
|
Item Number: C5216X1010
Package Weight: 0.3 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
C5216X1212
|
Log in to view price |
|
Item Number: C5216X1212
Package Weight: 0.5 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | Straight | 3,000 P.S.I. | 1 |
C5216X1616
|
Log in to view price |
|
Item Number: C5216X1616
Package Weight: 0.6 lbs
|
||||||||
SAE JIC 37° to Straight Thread Connectors
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
Tube OD: 1/8"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 5/16"-24 | Carbon Steel | Straight | 5,000 P.S.I. | 3 |
C5315X2
|
Log in to view price |
|
Item Number: C5315X2
Package Weight: 0.1 lbs
|
|||||||
Tube OD: 3/16"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/16" | 3/8"-24 | Carbon Steel | Straight | 5,000 P.S.I. | 3 |
C5315X3
|
Log in to view price |
|
Item Number: C5315X3
Package Weight: 0.1 lbs
|
|||||||
Tube OD: 1/4"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5315X4
|
Log in to view price |
|
Item Number: C5315X4
Package Weight: 0.3 lbs
|
|||||||
| 5/16" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 4 |
C5315X4X5
|
Log in to view price |
|
Item Number: C5315X4X5
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 4 |
C5315X4X6
|
Log in to view price |
|
Item Number: C5315X4X6
Package Weight: 0.3 lbs
|
|||||||
| 1/2" | 7/16"-20 | Carbon Steel | Straight | 4,500 P.S.I. | 4 |
C5315X4X8
|
Log in to view price |
|
Item Number: C5315X4X8
Package Weight: 0.5 lbs
|
|||||||
Tube OD: 5/16"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 2 |
C5315X5X4
|
Log in to view price |
|
Item Number: C5315X5X4
Package Weight: 0.1 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5315X5
|
Log in to view price |
|
Item Number: C5315X5
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5315X5X6
|
Log in to view price |
|
Item Number: C5315X5X6
Package Weight: 0.4 lbs
|
|||||||
Tube OD: 3/8"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5315X6X4
|
Log in to view price |
|
Item Number: C5315X6X4
Package Weight: 0.3 lbs
|
|||||||
| 5/16" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5315X6X5
|
Log in to view price |
|
Item Number: C5315X6X5
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5315X6
|
Log in to view price |
|
Item Number: C5315X6
Package Weight: 0.3 lbs
|
|||||||
SAE JIC 37° to O-Ring Face-Seal Swivels
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Straight | 6,000 P.S.I. | 1 |
4213X4
|
Log in to view price |
|
Item Number: 4213X4
Package Weight: 0.1 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 1 |
4213X6
|
Log in to view price |
|
Item Number: 4213X6
Package Weight: 0.1 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Straight | 4,000 P.S.I. | 1 |
4213X8
|
Log in to view price |
|
Item Number: 4213X8
Package Weight: 0.2 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
4213X10
|
Log in to view price |
|
Item Number: 4213X10
Package Weight: 0.3 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
4213X12
|
Log in to view price |
|
Item Number: 4213X12
Package Weight: 0.6 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
4213X16
|
Log in to view price |
|
Item Number: 4213X16
Package Weight: 0.9 lbs
|
|||||||
SAE JIC 37° Female Connectors
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/8" | 1/8" | 5/16"-24 | Carbon Steel | Straight | 5,000 P.S.I. | 1 |
C5255X2
|
Log in to view price |
|
Item Number: C5255X2
Package Weight: 0.1 lbs
|
||||||||
| 1/4" | 1/8" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5255X4
|
Log in to view price |
|
Item Number: C5255X4
Package Weight: 0.2 lbs
|
||||||||
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5255X4X4
|
Log in to view price |
|
Item Number: C5255X4X4
Package Weight: 0.5 lbs
|
||||||||
| 5/16" | 1/8" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5255X5
|
Log in to view price |
|
Item Number: C5255X5
Package Weight: 0.3 lbs
|
||||||||
| 5/16" | 1/4" | 1/2"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 2 |
C5255X5X4
|
Log in to view price |
|
Item Number: C5255X5X4
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 1/4" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 5 |
C5255X6
|
Log in to view price |
|
Item Number: C5255X6
Package Weight: 0.5 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 2 |
C5255X6X6
|
Log in to view price |
|
Item Number: C5255X6X6
Package Weight: 0.3 lbs
|
||||||||
| 1/2" | 3/8" | 3/4"-16 | Carbon Steel | Straight | 4,500 P.S.I. | 2 |
C5255X8
|
Log in to view price |
|
Item Number: C5255X8
Package Weight: 0.3 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | Straight | 4,500 P.S.I. | 2 |
C5255X8X8
|
Log in to view price |
|
Item Number: C5255X8X8
Package Weight: 0.6 lbs
|
||||||||
| 5/8" | 1/2" | 7/8"-14 | Carbon Steel | Straight | 3,500 P.S.I. | 2 |
C5255X10
|
Log in to view price |
|
Item Number: C5255X10
Package Weight: 0.6 lbs
|
||||||||
| 3/4" | 1/2" | 1-1/16"-12 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
C5255X12X8
|
Log in to view price |
|
Item Number: C5255X12X8
Package Weight: 0.3 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
C5255X12
|
Log in to view price |
|
Item Number: C5255X12
Package Weight: 0.5 lbs
|
||||||||
SAE JIC 37° Swivel to Pipe Adapters
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | Straight | 5,000 P.S.I. | 1 |
C5256X4X4
|
Log in to view price |
|
Item Number: C5256X4X4
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | Straight | 5,000 P.S.I. | 1 |
C5256X6X6
|
Log in to view price |
|
Item Number: C5256X6X6
Package Weight: 0.2 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | Straight | 4,500 P.S.I. | 1 |
C5256X8X8
|
Log in to view price |
|
Item Number: C5256X8X8
Package Weight: 0.3 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | Straight | 3,500 P.S.I. | 1 |
C5256X12
|
Log in to view price |
|
Item Number: C5256X12
Package Weight: 0.5 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | Straight | 3,000 P.S.I. | 1 |
C5256X16
|
Log in to view price |
|
Item Number: C5256X16
Package Weight: 0.8 lbs
|
||||||||
SAE JIC 37° Male 45° Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
Tube OD: 1/8"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 5/16"-24 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 1 |
C5355X2
|
Log in to view price |
|
Item Number: C5355X2
Package Weight: 0.1 lbs
|
|||||||
Tube OD: 3/16"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 3/8"-24 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 1 |
C5355X3
|
Log in to view price |
|
Item Number: C5355X3
Package Weight: 0.1 lbs
|
|||||||
Tube OD: 1/4"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 7/16"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X4
|
Log in to view price |
|
Item Number: C5355X4
Package Weight: 0.1 lbs
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X4X4
|
Log in to view price |
|
Item Number: C5355X4X4
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 7/16"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X4X6
|
Log in to view price |
|
Item Number: C5355X4X6
Package Weight: 0.3 lbs
|
|||||||
Tube OD: 5/16"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 1/2"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X5
|
Log in to view price |
|
Item Number: C5355X5
Package Weight: 0.2 lbs
|
|||||||
| 1/4" | 1/2"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X5X4
|
Log in to view price |
|
Item Number: C5355X5X4
Package Weight: 0.2 lbs
|
|||||||
Tube OD: 3/8"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 9/16"-18 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X6X2
|
Log in to view price |
|
Item Number: C5355X6X2
Package Weight: 0.2 lbs
|
|||||||
| 1/4" | 9/16"-18 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X6
|
Log in to view price |
|
Item Number: C5355X6
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5355X6X6
|
Log in to view price |
|
Item Number: C5355X6X6
Package Weight: 0.4 lbs
|
|||||||
| 1/2" | 9/16"-18 | Carbon Steel | 45° Elbow | 4,500 P.S.I. | 2 |
C5355X6X8
|
Log in to view price |
|
Item Number: C5355X6X8
Package Weight: 0.5 lbs
|
|||||||
Tube OD: 1/2"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 3/4"-16 | Carbon Steel | 45° Elbow | 4,500 P.S.I. | 2 |
C5355X8X4
|
Log in to view price |
|
Item Number: C5355X8X4
Package Weight: 0.4 lbs
|
|||||||
SAE JIC 37° Swivel Nut 45° Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5356X4
|
Log in to view price |
|
Item Number: C5356X4
Package Weight: 0.1 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 1 |
C5356X5
|
Log in to view price |
|
Item Number: C5356X5
Package Weight: 0.1 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5356X6
|
Log in to view price |
|
Item Number: C5356X6
Package Weight: 0.3 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | 45° Elbow | 4,500 P.S.I. | 2 |
C5356X8
|
Log in to view price |
|
Item Number: C5356X8
Package Weight: 1.8 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | 45° Elbow | 3,500 P.S.I. | 1 |
C5356X10
|
Log in to view price |
|
Item Number: C5356X10
Package Weight: 0.3 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | 45° Elbow | 3,500 P.S.I. | 1 |
C5356X12
|
Log in to view price |
|
Item Number: C5356X12
Package Weight: 0.5 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | 45° Elbow | 3,000 P.S.I. | 1 |
C5356X16
|
Log in to view price |
|
Item Number: C5356X16
Package Weight: 0.8 lbs
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | 45° Elbow | 2,500 P.S.I. | 1 |
C5356X20
|
Log in to view price |
|
Item Number: C5356X20
Package Weight: 1.5 lbs
|
|||||||
SAE JIC 37° Bulkhead Union Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made from Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5525X6
|
Log in to view price |
|
Item Number: C5525X6
Package Weight: 0.6 lbs
|
|||||||
SAE JIC 37° 90° Long Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/8" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5425X4
|
Log in to view price |
|
Item Number: C5425X4
Package Weight: 0.3 lbs
|
||||||||
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5425X4X4
|
Log in to view price |
|
Item Number: C5425X4X4
Package Weight: 0.5 lbs
|
||||||||
| 3/8" | 1/4" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5425X6
|
Log in to view price |
|
Item Number: C5425X6
Package Weight: 0.6 lbs
|
||||||||
| 1/2" | 3/8" | 3/4"-16 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 2 |
C5425X8
|
Log in to view price |
|
Item Number: C5425X8
Package Weight: 0.5 lbs
|
||||||||
| 5/8" | 1/2" | 7/8"-14 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 2 |
C5425X10
|
Log in to view price |
|
Item Number: C5425X10
Package Weight: 0.8 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 1 |
C5425X12
|
Log in to view price |
|
Item Number: C5425X12
Package Weight: 0.7 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | 90° Elbow | 3,000 P.S.I. | 1 |
C5425X16
|
Log in to view price |
|
Item Number: C5425X16
Package Weight: 1.1 lbs
|
||||||||
SAE JIC 37° 90° Extra Long Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/8" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 3 |
C5435X4
|
Log in to view price |
|
Item Number: C5435X4
Package Weight: 0.5 lbs
|
||||||||
| 3/8" | 1/4" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 3 |
C5435X6
|
Log in to view price |
|
Item Number: C5435X6
Package Weight: 0.5 lbs
|
||||||||
SAE JIC 37° Female 90° Elbows
Hydraulic, instrumentation, and chemical processing systems. Pressure rated up to 10,000 P.S.I. depending on tube and fitting size. Good vibration resistance, decreasing with tube size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a zinc, yellow dichromate finish. Used with various tubing types. Choice of 2 or 3 piece design. Meets ASA, ASME, SAE, and MS specifications.
| Tube OD | Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/8" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5455X4
|
Log in to view price |
|
Item Number: C5455X4
Package Weight: 0.2 lbs
|
||||||||
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5455X4X4
|
Log in to view price |
|
Item Number: C5455X4X4
Package Weight: 0.3 lbs
|
||||||||
| 3/8" | 1/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5455X6X2
|
Log in to view price |
|
Item Number: C5455X6X2
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 1/4" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5455X6
|
Log in to view price |
|
Item Number: C5455X6
Package Weight: 0.3 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5455X6X6
|
Log in to view price |
|
Item Number: C5455X6X6
Package Weight: 0.5 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 2 |
C5455X8X8
|
Log in to view price |
|
Item Number: C5455X8X8
Package Weight: 0.9 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 1 |
C5455X12
|
Log in to view price |
|
Item Number: C5455X12
Package Weight: 0.9 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | 90° Elbow | 3,000 P.S.I. | 1 |
C5455X16
|
Log in to view price |
|
Item Number: C5455X16
Package Weight: 1.3 lbs
|
||||||||
| 1-1/4" | 1-1/4" | 1-5/8"-12 | Carbon Steel | 90° Elbow | 2,500 P.S.I. | 1 |
C5455X20
|
Log in to view price |
|
Item Number: C5455X20
Package Weight: 2.1 lbs
|
||||||||
| 1-1/2" | 1-1/2" | 1-7/8"-12 | Carbon Steel | 90° Elbow | 2,000 P.S.I. | 1 |
C5455X24
|
Log in to view price |
|
Item Number: C5455X24
Package Weight: 4 lbs
|
||||||||
SAE JIC 37° 90° Swivel Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made from Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5506X4
|
Log in to view price |
|
Item Number: C5506X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5506X5
|
Log in to view price |
|
Item Number: C5506X5
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5506X6
|
Log in to view price |
|
Item Number: C5506X6
Package Weight: 0.3 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 2 |
C5506X8
|
Log in to view price |
|
Item Number: C5506X8
Package Weight: 0.5 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 2 |
C5506X10
|
Log in to view price |
|
Item Number: C5506X10
Package Weight: 0.8 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 2 |
C5506X12
|
Log in to view price |
|
Item Number: C5506X12
Package Weight: 1.3 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | 90° Elbow | 3,000 P.S.I. | 1 |
C5506X16
|
Log in to view price |
|
Item Number: C5506X16
Package Weight: 1 lbs
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | 90° Elbow | 2,500 P.S.I. | 1 |
C5506X20
|
Log in to view price |
|
Item Number: C5506X20
Package Weight: 1.9 lbs
|
|||||||
| 1-1/2" | 1-7/8"-12 | Carbon Steel | 90° Elbow | 2,000 P.S.I. | 1 |
C5506X24
|
Log in to view price |
|
Item Number: C5506X24
Package Weight: 2.6 lbs
|
|||||||
SAE JIC 37° to Straight Thread Male 45° Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 4 |
C5365X4
|
Log in to view price |
|
Item Number: C5365X4
Package Weight: 0.3 lbs
|
||||||||
| 5/16" | 5/16" | 1/2"-20 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5365X5
|
Log in to view price |
|
Item Number: C5365X5
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | 45° Elbow | 5,000 P.S.I. | 2 |
C5365X6
|
Log in to view price |
|
Item Number: C5365X6
Package Weight: 0.3 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | 45° Elbow | 4,500 P.S.I. | 2 |
C5365X8
|
Log in to view price |
|
Item Number: C5365X8
Package Weight: 0.5 lbs
|
||||||||
| 1/2" | 5/8" | 3/4"-16 | Carbon Steel | 45° Elbow | 3,500 P.S.I. | 2 |
C5365X8X10
|
Log in to view price |
|
Item Number: C5365X8X10
Package Weight: 0.6 lbs
|
||||||||
| 5/8" | 5/8" | 7/8"-14 | Carbon Steel | 45° Elbow | 3,500 P.S.I. | 2 |
C5365X10
|
Log in to view price |
|
Item Number: C5365X10
Package Weight: 0.7 lbs
|
||||||||
| 3/4" | 5/8" | 1-1/16"-12 | Carbon Steel | 45° Elbow | 3,500 P.S.I. | 1 |
C5365X1210
|
Log in to view price |
|
Item Number: C5365X1210
Package Weight: 0.5 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | 45° Elbow | 3,500 P.S.I. | 1 |
C5365X12
|
Log in to view price |
|
Item Number: C5365X12
Package Weight: 0.6 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | 45° Elbow | 3,000 P.S.I. | 1 |
C5365X16
|
Log in to view price |
|
Item Number: C5365X16
Package Weight: 0.8 lbs
|
||||||||
SAE JIC 37° 90° Union Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 3 |
C5505X4
|
Log in to view price |
|
Item Number: C5505X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 3 |
C5505X5
|
Log in to view price |
|
Item Number: C5505X5
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 3 |
C5505X6
|
Log in to view price |
|
Item Number: C5505X6
Package Weight: 0.4 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 3 |
C5505X8
|
Log in to view price |
|
Item Number: C5505X8
Package Weight: 0.7 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 2 |
C5505X10
|
Log in to view price |
|
Item Number: C5505X10
Package Weight: 0.7 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 2 |
C5505X12
|
Log in to view price |
|
Item Number: C5505X12
Package Weight: 1.2 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | 90° Elbow | 3,000 P.S.I. | 1 |
C5505X16
|
Log in to view price |
|
|
|||||||
SAE JIC 37° Male 90° Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Choice of 2 or 3 piece design, meeting ASA, ASME, SAE, and MS standards.
Tube OD: 1/8"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 5/16"-24 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5405X2
|
Log in to view price |
|
Item Number: C5405X2
Package Weight: 0.1 lbs
|
|||||||
Tube OD: 3/16"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 3/8"-24 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X3
|
Log in to view price |
|
Item Number: C5405X3
Package Weight: 0.2 lbs
|
|||||||
Tube OD: 1/4"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X4
|
Log in to view price |
|
Item Number: C5405X4
Package Weight: 0.3 lbs
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X4X4
|
Log in to view price |
|
Item Number: C5405X4X4
Package Weight: 0.5 lbs
|
|||||||
| 3/8" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X4X6
|
Log in to view price |
|
Item Number: C5405X4X6
Package Weight: 0.8 lbs
|
|||||||
| 1/2" | 7/16"-20 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 2 |
C5405X4X8
|
Log in to view price |
|
Item Number: C5405X4X8
Package Weight: 0.6 lbs
|
|||||||
Tube OD: 5/16"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 1/2"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X5
|
Log in to view price |
|
Item Number: C5405X5
Package Weight: 0.4 lbs
|
|||||||
| 1/4" | 1/2"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X5X4
|
Log in to view price |
|
Item Number: C5405X5X4
Package Weight: 0.5 lbs
|
|||||||
Tube OD: 3/8"
| Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X6X2
|
Log in to view price |
|
Item Number: C5405X6X2
Package Weight: 0.4 lbs
|
|||||||
| 1/4" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X6
|
Log in to view price |
|
Item Number: C5405X6
Package Weight: 0.5 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 4 |
C5405X6X6
|
Log in to view price |
|
Item Number: C5405X6X6
Package Weight: 0.8 lbs
|
|||||||
| 1/2" | 9/16"-18 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 4 |
C5405X6X8
|
Log in to view price |
|
Item Number: C5405X6X8
Package Weight: 1.1 lbs
|
|||||||
SAE JIC 37° to Pipe 90° Swivel Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/8" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5406X4
|
Log in to view price |
|
Item Number: C5406X4
Package Weight: 0.2 lbs
|
||||||||
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5406X4X4
|
Log in to view price |
|
Item Number: C5406X4X4
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 1/4" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5406X6
|
Log in to view price |
|
Item Number: C5406X6
Package Weight: 0.3 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5406X6X6
|
Log in to view price |
|
Item Number: C5406X6X6
Package Weight: 0.4 lbs
|
||||||||
| 3/8" | 1/2" | 9/16"-18 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 1 |
C5406X6X8
|
Log in to view price |
|
Item Number: C5406X6X8
Package Weight: 0.4 lbs
|
||||||||
| 1/2" | 3/8" | 3/4"-16 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 2 |
C5406X8
|
Log in to view price |
|
Item Number: C5406X8
Package Weight: 0.5 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 2 |
C5406X8X8
|
Log in to view price |
|
Item Number: C5406X8X8
Package Weight: 0.7 lbs
|
||||||||
| 5/8" | 1/2" | 7/8"-14 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 1 |
C5406X10
|
Log in to view price |
|
Item Number: C5406X10
Package Weight: 0.4 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 1 |
C5406X12
|
Log in to view price |
|
Item Number: C5406X12
Package Weight: 0.6 lbs
|
||||||||
| 7/8" | 3/4" | 1-3/16"-12 | Carbon Steel | 90° Elbow | 3,000 P.S.I. | 1 |
C5406X14
|
Log in to view price |
|
Item Number: C5406X14
Package Weight: 0.6 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | 90° Elbow | 3,000 P.S.I. | 1 |
C5406X16
|
Log in to view price |
|
Item Number: C5406X16
Package Weight: 1 lbs
|
||||||||
SAE JIC 37° to Straight Thread 90° Elbows
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
Tube OD: 3/16"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/16" | 3/8"-24 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 1 |
C5515X3
|
Log in to view price |
|
Item Number: C5515X3
Package Weight: 0.1 lbs
|
|||||||
Tube OD: 1/4"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X4
|
Log in to view price |
|
Item Number: C5515X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X4X5
|
Log in to view price |
|
Item Number: C5515X4X5
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 7/16"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X4X6
|
Log in to view price |
|
Item Number: C5515X4X6
Package Weight: 0.3 lbs
|
|||||||
Tube OD: 5/16"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 1/2"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X5X4
|
Log in to view price |
|
Item Number: C5515X5X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X5
|
Log in to view price |
|
Item Number: C5515X5
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 1/2"-20 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X5X6
|
Log in to view price |
|
Item Number: C5515X5X6
Package Weight: 0.3 lbs
|
|||||||
Tube OD: 3/8"
| Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X6X4
|
Log in to view price |
|
Item Number: C5515X6X4
Package Weight: 0.3 lbs
|
|||||||
| 5/16" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X6X5
|
Log in to view price |
|
Item Number: C5515X6X5
Package Weight: 0.3 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 5,000 P.S.I. | 2 |
C5515X6
|
Log in to view price |
|
Item Number: C5515X6
Package Weight: 0.3 lbs
|
|||||||
| 1/2" | 9/16"-18 | Carbon Steel | 90° Elbow | 4,500 P.S.I. | 2 |
C5515X6X8
|
Log in to view price |
|
Item Number: C5515X6X8
Package Weight: 0.5 lbs
|
|||||||
| 5/8" | 9/16"-18 | Carbon Steel | 90° Elbow | 3,500 P.S.I. | 2 |
C5515X6X10
|
Log in to view price |
|
Item Number: C5515X6X10
Package Weight: 0.8 lbs
|
|||||||
SAE JIC 37° Union Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/16" | 3/8"-24 | Carbon Steel | Tee | 5,000 P.S.I. | 1 |
C5705X3
|
Log in to view price |
|
|
|||||||
| 1/4" | 7/16"-20 | Carbon Steel | Tee | 5,000 P.S.I. | 2 |
C5705X4
|
Log in to view price |
|
Item Number: C5705X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Tee | 5,000 P.S.I. | 2 |
C5705X5
|
Log in to view price |
|
Item Number: C5705X5
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Tee | 5,000 P.S.I. | 2 |
C5705X6
|
Log in to view price |
|
Item Number: C5705X6
Package Weight: 0.3 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Tee | 4,500 P.S.I. | 2 |
C5705X8
|
Log in to view price |
|
Item Number: C5705X8
Package Weight: 0.6 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Tee | 3,500 P.S.I. | 1 |
C5705X10
|
Log in to view price |
|
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Tee | 3,500 P.S.I. | 1 |
C5705X12
|
Log in to view price |
|
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Tee | 3,000 P.S.I. | 1 |
C5705X16
|
Log in to view price |
|
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Tee | 2,500 P.S.I. | 1 |
C5705X20
|
Log in to view price |
|
|
|||||||
SAE JIC 37° Male Run Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Male Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | Tee | 5,000 P.S.I. | 3 |
C5755X4X4
|
Log in to view price |
|
Item Number: C5755X4X4
Package Weight: 0.4 lbs
|
||||||||
| 3/8" | 1/4" | 9/16"-18 | Carbon Steel | Tee | 5,000 P.S.I. | 3 |
C5755X6
|
Log in to view price |
|
Item Number: C5755X6
Package Weight: 0.4 lbs
|
||||||||
| 1/2" | 3/8" | 3/4"-16 | Carbon Steel | Tee | 4,500 P.S.I. | 3 |
C5755X8
|
Log in to view price |
|
Item Number: C5755X8
Package Weight: 0.8 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | Tee | 4,500 P.S.I. | 1 |
C5755X8X8
|
Log in to view price |
|
Item Number: C5755X8X8
Package Weight: 0.4 lbs
|
||||||||
| 5/8" | 1/2" | 7/8"-14 | Carbon Steel | Tee | 3,500 P.S.I. | 1 |
C5755X10
|
Log in to view price |
|
Item Number: C5755X10
Package Weight: 0.4 lbs
|
||||||||
SAE JIC 37° Swivel Run Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Tee | 5,000 P.S.I. | 2 |
C5706X4
|
Log in to view price |
|
Item Number: C5706X4
Package Weight: 0.2 lbs
|
|||||||
| 5/16" | 1/2"-20 | Carbon Steel | Tee | 5,000 P.S.I. | 2 |
C5706X5
|
Log in to view price |
|
Item Number: C5706X5
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Tee | 5,000 P.S.I. | 2 |
C5706X6
|
Log in to view price |
|
Item Number: C5706X6
Package Weight: 0.4 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Tee | 4,500 P.S.I. | 2 |
C5706X8
|
Log in to view price |
|
Item Number: C5706X8
Package Weight: 0.6 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Tee | 3,500 P.S.I. | 1 |
C5706X10
|
Log in to view price |
|
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Tee | 3,500 P.S.I. | 1 |
C5706X12
|
Log in to view price |
|
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Tee | 3,000 P.S.I. | 1 |
C5706X16
|
Log in to view price |
|
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Tee | 2,500 P.S.I. | 1 |
C5706X20
|
Log in to view price |
|
Item Number: C5706X20
Package Weight: 2.1 lbs
|
|||||||
| 1-1/2" | 1-7/8"-12 | Carbon Steel | Tee | 2,000 P.S.I. | 1 |
C5706X24
|
Log in to view price |
|
Item Number: C5706X24
Package Weight: 2.8 lbs
|
|||||||
SAE JIC 37° to Straight Thread Male Run Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | Tee | 5,000 P.S.I. | 2 |
C5716X4
|
Log in to view price |
|
Item Number: C5716X4
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | Tee | 4,500 P.S.I. | 2 |
C5716X6
|
Log in to view price |
|
Item Number: C5716X6
Package Weight: 0.3 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | Tee | 4,500 P.S.I. | 2 |
C5716X8
|
Log in to view price |
|
Item Number: C5716X8
Package Weight: 0.7 lbs
|
||||||||
| 5/8" | 5/8" | 7/8"-14 | Carbon Steel | Tee | 3,500 P.S.I. | 1 |
C5716X10
|
Log in to view price |
|
Item Number: C5716X10
Package Weight: 0.5 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | Tee | 3,500 P.S.I. | 1 |
C5716X12
|
Log in to view price |
|
Item Number: C5716X12
Package Weight: 0.8 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | Tee | 3,000 P.S.I. | 1 |
C5716X16
|
Log in to view price |
|
Item Number: C5716X16
Package Weight: 1.2 lbs
|
||||||||
| 1-1/4" | 1-1/4" | 1-5/8"-12 | Carbon Steel | Tee | 2,500 P.S.I. | 1 |
C5716X20
|
Log in to view price |
|
Item Number: C5716X20
Package Weight: 2 lbs
|
||||||||
| 1-1/2" | 1-1/2" | 1-7/8"-12 | Carbon Steel | Tee | 2,000 P.S.I. | 1 |
C5716X24
|
Log in to view price |
|
Item Number: C5716X24
Package Weight: 2.7 lbs
|
||||||||
SAE JIC 37° Male Branch Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Male Pipe Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/8" | 7/16"-20 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 2 |
C5605X4
|
Log in to view price |
|
Item Number: C5605X4
Package Weight: 0.2 lbs
|
||||||||
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 2 |
C5605X4X4
|
Log in to view price |
|
Item Number: C5605X4X4
Package Weight: 0.2 lbs
|
||||||||
| 3/8" | 1/4" | 9/16"-18 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 2 |
C5605X6
|
Log in to view price |
|
Item Number: C5605X6
Package Weight: 0.6 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 2 |
C5605X6X6
|
Log in to view price |
|
Item Number: C5605X6X6
Package Weight: 0.4 lbs
|
||||||||
| 1/2" | 3/8" | 3/4"-16 | Carbon Steel | Branch Tee | 4,500 P.S.I. | 2 |
C5605X8
|
Log in to view price |
|
Item Number: C5605X8
Package Weight: 0.6 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | Branch Tee | 4,500 P.S.I. | 2 |
C5605X8X8
|
Log in to view price |
|
Item Number: C5605X8X8
Package Weight: 0.7 lbs
|
||||||||
| 5/8" | 5/8" | 7/8"-14 | Carbon Steel | Branch Tee | 3,500 P.S.I. | 2 |
C5605X10
|
Log in to view price |
|
Item Number: C5605X10
Package Weight: 0.8 lbs
|
||||||||
| 3/4" | 3/4" | 1-1/16"-12 | Carbon Steel | Branch Tee | 3,500 P.S.I. | 1 |
C5605X12
|
Log in to view price |
|
Item Number: C5605X12
Package Weight: 0.7 lbs
|
||||||||
| 1" | 1" | 1-5/16"-12 | Carbon Steel | Branch Tee | 3,000 P.S.I. | 1 |
C5605X16
|
Log in to view price |
|
Item Number: C5605X16
Package Weight: 1 lbs
|
||||||||
SAE JIC 37° Female Swivel Branch Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 2 |
C5707X4
|
Log in to view price |
|
Item Number: C5707X4
Package Weight: 0.2 lbs
|
|||||||
| 3/8" | 9/16"-18 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 2 |
C5707X6
|
Log in to view price |
|
Item Number: C5707X6
Package Weight: 0.3 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Branch Tee | 4,500 P.S.I. | 2 |
C5707X8
|
Log in to view price |
|
Item Number: C5707X8
Package Weight: 0.6 lbs
|
|||||||
| 5/8" | 7/8"-14 | Carbon Steel | Branch Tee | 3,500 P.S.I. | 2 |
C5707X10
|
Log in to view price |
|
Item Number: C5707X10
Package Weight: 0.9 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Branch Tee | 3,500 P.S.I. | 1 |
C5707X12
|
Log in to view price |
|
Item Number: C5707X12
Package Weight: 0.8 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Branch Tee | 3,000 P.S.I. | 1 |
C5707X16
|
Log in to view price |
|
Item Number: C5707X16
Package Weight: 1.1 lbs
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Branch Tee | 2,500 P.S.I. | 1 |
C5707X20
|
Log in to view price |
|
Item Number: C5707X20
Package Weight: 2.1 lbs
|
|||||||
| 1-1/2" | 1-7/8"-12 | Carbon Steel | Branch Tee | 2,000 P.S.I. | 1 |
C5707X24
|
Log in to view price |
|
Item Number: C5707X24
Package Weight: 2.9 lbs
|
|||||||
SAE JIC 37° Bulkhead Branch Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/8" | 9/16"-18 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 1 |
C5725X6
|
Log in to view price |
|
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Branch Tee | 4,500 P.S.I. | 1 |
C5725X8
|
Log in to view price |
|
|
|||||||
SAE JIC 37° to Straight Thread Male Branch Tees
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
| Tube OD | Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|---|
| 1/4" | 1/4" | 7/16"-20 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 1 |
C5715X4
|
Log in to view price |
|
Item Number: C5715X4
Package Weight: 0.1 lbs
|
||||||||
| 3/8" | 3/8" | 9/16"-18 | Carbon Steel | Branch Tee | 5,000 P.S.I. | 1 |
C5715X6
|
Log in to view price |
|
Item Number: C5715X6
Package Weight: 0.2 lbs
|
||||||||
| 1/2" | 1/2" | 3/4"-16 | Carbon Steel | Branch Tee | 4,500 P.S.I. | 1 |
C5715X8
|
Log in to view price |
|
Item Number: C5715X8
Package Weight: 0.4 lbs
|
||||||||
Straight Thread O-Ring Adapters
Designed for hydraulic, instrumentation, and chemical processing systems. Pressure ratings up to 10,000 P.S.I. depending on tube and fitting size. Temperature range from -65°F to +400°F. Made of Carbon Steel - AISI/SAE 12L14 with a Zinc, yellow dichromate finish. Available in 2 or 3 piece designs, meeting ASA, ASME, SAE, and MS standards.
Female Port Size: 1/4"
| Male Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 3/8" | 9/16"-18 | Carbon Steel | Straight | 4,000 P.S.I. | 2 |
7033X6X4
|
Log in to view price |
|
Item Number: 7033X6X4
Package Weight: 0.1 lbs
|
|||||||
Female Port Size: 3/8"
| Male Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/4" | 7/16"-20 | Carbon Steel | Straight | 4,000 P.S.I. | 2 |
7033X4X6
|
Log in to view price |
|
Item Number: 7033X4X6
Package Weight: 0.2 lbs
|
|||||||
| 1/2" | 3/4"-16 | Carbon Steel | Straight | 4,000 P.S.I. | 2 |
7033X8X6
|
Log in to view price |
|
Item Number: 7033X8X6
Package Weight: 0.3 lbs
|
|||||||
Female Port Size: 1/2"
| Male Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 5/8" | 7/8"-14 | Carbon Steel | Straight | 3,000 P.S.I. | 2 |
7033X10X8
|
Log in to view price |
|
Item Number: 7033X10X8
Package Weight: 0.3 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Straight | 3,000 P.S.I. | 2 |
7033X12X8
|
Log in to view price |
|
Item Number: 7033X12X8
Package Weight: 0.4 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Straight | 2,500 P.S.I. | 1 |
7033X16X8
|
Log in to view price |
|
Item Number: 7033X16X8
Package Weight: 0.4 lbs
|
|||||||
Female Port Size: 5/8"
| Male Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 1/2" | 3/4"-16 | Carbon Steel | Straight | 3,000 P.S.I. | 2 |
7033X8X10
|
Log in to view price |
|
Item Number: 7033X8X10
Package Weight: 0.4 lbs
|
|||||||
| 3/4" | 1-1/16"-12 | Carbon Steel | Straight | 3,000 P.S.I. | 2 |
7033X12X10
|
Log in to view price |
|
Item Number: 7033X12X10
Package Weight: 0.6 lbs
|
|||||||
Female Port Size: 3/4"
| Male Port Size | Thread Size | Material | Shape | Maximum Pressure | Package Qty | Item # |
Price
Want to view pricing for this product?
Log In or Create Login Not a Kimball Midwest Customer? Register |
|---|---|---|---|---|---|---|---|
| 5/8" | 7/8"-14 | Carbon Steel | Straight | 3,000 P.S.I. | 2 |
7033X10X12
|
Log in to view price |
|
Item Number: 7033X10X12
Package Weight: 0.6 lbs
|
|||||||
| 7/8" | 1-3/16"-12 | Carbon Steel | Straight | 2,500 P.S.I. | 1 |
7033X14X12
|
Log in to view price |
|
Item Number: 7033X14X12
Package Weight: 0.4 lbs
|
|||||||
| 1" | 1-5/16"-12 | Carbon Steel | Straight | 2,500 P.S.I. | 1 |
7033X16X12
|
Log in to view price |
|
Item Number: 7033X16X12
Package Weight: 0.5 lbs
|
|||||||
| 1-1/4" | 1-5/8"-12 | Carbon Steel | Straight | 2,000 P.S.I. | 1 |
7033X20X12
|
Log in to view price |
|
Item Number: 7033X20X12
Package Weight: 0.6 lbs
|
|||||||
Top
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 1
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Price
Want to view pricing for this product?
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Log In or Create Login
Not a Kimball Midwest Customer?
Register
Pkg Qty: 2
Digital Catalog
View Catalog
